Innovative Digital Imaging.

The AirDR™P is a durable 14"x17" DR panel offered in Gadox or Cesium, loaded with cutting edge features that ensures patients receive the lowest possible dose.



This Flat Panel Detector uses a low-power WiFi connection to transmit images, allowing you the freedom to capture difficult or unusual x-ray projections. With a thin and sturdy carbon fiber frame and wireless capabilities, it can be seamlessly integrated into new or existing x-ray rooms.



Rugged and reliable, the AirDR™P has achieved a high Water and Dust rating of IP42 to protect it from outside dust particles, and if accidentally wet, it is engineered to protect the panel and prevent the circuits from shorting out.

127

Micron

16 Bit

Resolution

9.4

Megapixel

3 X-ray.png
AirDR P c Logo Blue.png

Like its AirDR™-P counterpart, the  AirDR™Pc is a durable, low-dose 17"x17" Wired DR panel equipped with directly deposited Gadox or Cesium Scintillator which proves unparalleled image quality.



The detector provides integrated AED (Automatic Exposure Detection) which allows for seamless, retrofit integration and no-hassle implementation into your practice. The AirDR™-Pc system is compatible with any X-Ray system to work with 43x 43 cm cassettes that comply with ISO 4090.

Lightweight at only 7.7 lbs (3.5 kg)  has 140-micron active-matrix that guarantees image resolution up to 3.4 lp/mm. With an IP42 Water and Dust rating, the panel is designed to endure any unforeseen accidents.

16 Bit

Resolution

140

Micron

9.3

Megapixel

AirDR P c Logo Blue.png

Specifications



The AirDR™-P is a lightweight digital radiographic system designed to optimize workflow, increase throughput, and eliminate unnecessary exposures to patients. Its durable frame and wireless capabilities allow you to complete imaging freedom for even the most difficult image projections. Using advanced acquisition software, the AirDR™-P allows you to achieve unprecedented workflow and save valuable time.

Detector

The AirDR™-P is a 127-micron, direct deposit Cesium and Gadox scintillator, flat-panel detector. The detector transmits images to the acquisition station through a WiFi connection, eliminating the need for a hardwire cable. If WiFi is unavailable, a back-up cable connection can be used. Powered by a Cesium Iodide or Gadox Scintillator, the detector delivers high-resolution images at the lowest possible dose.

Single Sensor Detector

Other panels on the market can have as many as 5 separate sensors and the panel relies on these sensors to work in concert to acquire an image. Multi-sensor panels are often vulnerable to failure points between sensors, which can cause "no triggers" and "false triggers" during a routine study and ultimately lead to unnecessary repeat exposures for patients.

XC™ : ICE-4 Image Clarity Enhancement

The AirDR-P is designed to work iCRco’s proprietary software, X-ray Capture (XC). XC Acquisition software is powered by a multi-frequency processing algorithm known as Image Clarity Enhancement (ICE).



4th Generation ICE processing provides an image display state that ensures a balanced presentation of both soft tissue and overlapping bone structures and technology that improves image quality while preserving diagnostic detail for thicker body parts.

Simple, Intuitive Image Viewing

Clarity PACS : Storing, Reporting and Sending Images​​

The Claris XT scans images and over time storing and organizing those images becomes a necessity. For this reason, iCRco has a fully DICOM compliant Picture Archiving Communication System (PACS).

Clarity PACS is a scalable and affordable PACS designed to optimize imaging workflow and simplify image management processes, and it is fully web-enabled. It is designed to support all major modalities and includes a powerful web-viewer.
